Features
  • Manufactured by using High Thickness Zinc Alloy MPP dielectric
  • Withstands Higher Over voltage i.e. up to 15 % of Rated Voltage
  • Withstands Higher Over loads i.e. 40 % of Rated Current.
  • "Self healing" property ensures long life of the Capacitor
  • Low energy consumption i.e. Watt Loss
  • Fire Retardant Resin Encapsulation for better safety
  • Suitable for Banking
  • Weather proof Powder coating
  • Oil filled model made with high purity non-toxic oil, which keeps Capacitor cool and thereby ensures long life

Technical Specification
Reference IS IS 13340 / 1993.
Output Range 1 Kvar to 25 Kvar single units & above 25 Kvar in Banking.
Working Voltage 230 to 1000 Volts AC.
No. of Phases Single / Three.
Temp. Category 55 Deg. C Max.
Capacitance Tolerance 0 % to + 10 %
Permitted Over Voltage 1.15 Times of rated voltage
Permitted Over Current 1.40 Times of rated current.
Frequency 50 Hz.
Losses < 0.50 w / kvar
Cooling Natural air And Or Oil Cooling.
Installation Indoor, Floor Mounting
Life Expectancy 75,000 Hrs
In-rush Current 150 times of rated current.
Applications

Suitable for Three Phase Power Factor Correction of loads with 30 - 40 % load variation Process Industries, Chemical Plants, Pharmaceutical Industries, Cement Industries & Sugar plants etc.

We Are Manufacturer, Supplier & Exporter Of Capacitors
